Last update: 09.01.2024
| General | |
| Brand | Estelle |
| Device name | Estelle One |
| Model name | EST-001-BLK |
| Country of origin | China |
| Designed in | Sweden |
| Key points | Ultra-Portable: Fits into any commuter bag, ensuring big screen 100"+ entertainment on the go Intuitive Touch Screen: Easy navigation with a 6" touch screen interface for seamless control. Access to Google Play Store: Enjoy a wide array of apps, games, and content at your fingertips. |
| Included in the gift box | • Estelle One • Black Sleeve • Wall Mount • Charger • USB-C Cable • Cleaning Cloth • SIM card removal pin |
| Projector Optical parameters | |
| ID | |
| LCD | Size: 5.99" FHD+ Resolution: 2160*1080p Aspect ratio: 6:09:00 PM |
| High Dynamic Range (HDR) standard | Not supported |
| Touch Panel | G+FF 2.5D |
| Display Chip | Texas Instrument 0.23" 1080p DMD (3xLED RGB)(Ongine) |
| Optimized for gaming | yes |
| Display technology | DLP |
| Light scource | lamp |
| Contrast ratio | 350:1(Ongine) |
| Luminance | Typ. 200 lm |
| Estimated hours of lamp use | 20000 |
| Color processing | 8-bit |
| Projection Parameters | |
| Throw ratio | 1.25:1 (72"@2m) |
| Resolution of the projected image | 1920x1080px |
| Projected screen size min (inch) | 30 |
| Projected screen size max (inch) | 100+ |
| Projected screen size min (cm) | 76 cm(30”)(@80cm distance) |
| Projected screen size max (cm) | 254 cm(100”)(@280cm distance) |
| Maximum projection distance (m) | 3 |
| Minimum projection distance (m) | 0,5 |
| Focus adjustment | Auto and manual |
| Digital Keystone | Automatic vertical +-17° Automatic 2D Horizontal +-10° |
| 2D vertical refresh rate | 60 Hz |
| 2D horizontal refreshrate | N/a |
| Lens shift | supported |
| Zoom | digital |
| Off Axis | 100% and adjustable |
| Depth of Focus | 1cm@2m |
| Projection method | Front on wall Up on ceiling |
| Camera | Front: 2MP FF |
| Internal display | |
| Size | 5.99" FHD+ |
| Resolution | 2160*1080p |
| Technology | IPS |
| Brightness | 350 nit |
| Touch | Capacitive, Multi touch |
| Acoustics | |
|
Speaker
|
3W 4Ω BOX |
| 2W 4Ω BOX | |
| Audio support | FLAC |
| No. of integrated speakers | 2 |
| Mic | 2 Digital MICs |
| Noise | <45dBA@50cm@200lm |
| Noise eco mode (dB) | <35dB@50cm This is measured value @75% |
| Noise level max (dB) | <38dB@50cm |
| System parameters | |
|
CPU
|
Type: MTK8789 |
| Frequency: 2*2.05GHZ A76 + 6*2.0GHZ A55 | |
| GPU | Type: MALI G76-3EE MC4 |
|
Storage
|
RAM: 4GB |
| ROM: 64GB | |
| Extended Storage: micro-SDXC slot up to 512GB | |
|
Video Codecs
|
According to Android 11 CDD |
| HW acc. H.265/HEVC, H.264, SW decodec VP8/VP9 1080p@30fps | |
| OS | Android 12 |
| Automatic software updates | Supported |
| Wireless | |
| WiFi | 802.11b/g/n/ac |
| BT | Dual mode 5.0 |
| GPS/A-GPS | Internal |
| Bands | GSM: B2/B3/B5/B8(1900/1800/850/900MHz) WCDMA: 850 / 900 / 1900 / 2100 LTE: 1, 2, 3, 4, 5, 7, 8, 20, 34, 38, 39, 40, 41, B28ab |
| CA support TX | TX chain supports Intra-band carrier aggregation. The platform supports all UL intra-band CA use cases specified by 3GPP as of 2021. CA_1C, CA_3C, CA_7C, CA_38C, CA_40C, CA_41C |
| CA support RX | RX chain support intra-band, inter-band, contiguous and non-contiguous CA and MIMO |
| Screen mirroring | Supported |
| Bluetooth | Supported |
| DLNA | Supported |
| Smart home compatibility (works with) | Google Home |
| Sensors | |
| Sensors | Ambient light sensor 3D Accelerometer, 3D gyroscope Proximity sensor for embedded display |
| Connections | |
| Charging | USB-C PD |
| Datatransfer | USB 2.0 |
| Audio | 3.5mm stereo+mic |
| Display input | HDMI 1080p@60fps |
| No. of HDMI connections | 1 |
| External connectors | |
| USB | USB-C |
| Expansion memory | Micro SD |
| SIM card | nano SIM |
| Audio | ∮3.5mm |
| Display input | HDMI |
| Ethernet connection (RJ45) | Ready - Adapter required |
| Electrical | |
| Battery | Type: Li-Polymer Battery Battery specification: >80% capacity after 500 full charge/discharge cycles Capacity: 4000 mAh 11.6V (12000mAh 3.8V); 44,4Wh |
| Charging 0-80% | 1h |
| Charging indicator | Red charging/green charged |
| Typical user time | 3h streaming movie @ 100lm |
| Standby time | >1 week |
| Power consumption standby (Watt) | ~72mWatt@4G network@WIFI&BT ON@Average 30 min current value |
| Max. power consumption (watt) | 25 |
| Power consumption eco mode (watt) | 15 |
| Physical | |
| Dimensions without packaking (cm) | 6.07x17.45x8.72 |
| Height (cm) | 6.07 |
| Width (cm) | 17.45 |
| Depth (cm) | 8.72 |
| Dimensions with packaking (cm) | 145x225x125 |
| Height (cm) | 145 |
| Width (cm) | 225 |
| Depth (cm) | 125 |
| Net Weight of Estelle One, g | 955 |
| Net weight of Estelle On with accessories in the gift box, g | 1100 |
| Gross weight of Estelle On with accessories in the gift box, g | 1760 |
| Tripod mount | Standard 1/4-20 UNC mount |
| Color | Black |
| Main materials in the product | Alluminum, glass, silicone |
| Main materials in the gift box | Coated paper paperboard |
| Sustainability | |
| Eco mode | Available |
| Amount of product from recycled materials % | 99.98 |
| Amount of plastic content packaging | 0.1 |
| Amount of product possible to recycle | 80 |
| Availability of spare parts, years | 3 |
| Expected lifetime, years | 5 |
| User Interface | |
| Controllable by a remote control | Yes |
| Controllable by Smartphone/Tablet App | Yes |
| App available | Yes |
| Name of available app | Estelle One App |
